Automatic self-adjusting deck plates.
No operator’s intervention required.
olimac-drago201-en
TOTAL HARVESTING WITHOUT LOSSES OF KERNELS AND EARS
Olimac-Drago-2-automatic-self-adjusting-deck-plates

Unique in the world.
There are corn heads that leaves ears and kernels in the field: with Drago2 this does not happen.
Drago2 (together with DragoGT) is the only corn head in the world equipped with automatic and simultaneous self-adjusting deck plates according to the size of the stalk, without operator’s intervention: the automatism works independently on each row.
Harvesting is complete and without losses, Productivity is higher.

Longer stalk rollers
olimac-drago202
STALK PERFECTLY PRESSED
Olimac-Drago-2-longer-stalk-chopper

The stalk rollers are longer compared to the normal corn heads’ ones: the lower peripheral speed causes a gentler separation of the ear from the plant. The stalk is perfectly pressed, harvesting is complete without losses.

WATCH THE COMPARISON AMONG DRAGO 2
AND THE TRADITIONAL CORN HEADS
Olimac-Drago-2-in-campo-in-the-field-auf-dem-feld-en-acción
Low profile construction and working angle of only 18°
PERFECT HARVESTING OF ALL DOWN CORN
Olimac-Drago-2-low-profile-construction

Low profile construction.
The exclusive low-profile construction and the efficient work of the lateral augers determine a safe penetration of the down corn allowing for a total harvest of low-lying and hanging corns.
Lower working angle.
In working position, the inclination of the row-group with respect to the ground has a lower angle than most corn heads have: thanks to this special feature harvesting all down corn is not a problem anymore.
Besides, the low inclination of the row-group avoids the ears to bounce out of the machine.

Rotary blades stalk chopper
FIELD READY FOR PLOWING
Olimac-Drago-2-stalk-chopper

Upon request, Drago2 can be equipped with a built-in stalk chopper with rotary blades. With very low power consumption, the stalk chopper crushes the corn stalks leaving the field ready for plowing.

Long-lasting with minimal maintenance
OIL-BATHED TRANSMISSION COMPONENTS
Olimac-Drago-2-coppie-coniche-acciaio-temperato-catene-raccoglitrici-in-acciaio-rinforzato-facile-rapida-manutenzione-cylindrical-gears-in-hardened-steel-gathering-chains-in-reinforced-steel-easy-quick-maintenance-kegelradgetriebe-aus-gehaertetem-stahl-ernteketten-aus-gehaertetem-stahl-schnelle-einfache-wartung-pares-cónicos-acero-templado-cadenas-recolección-de-acero-reforzado-fácil-rápido-mantenimiento

Hardened steel bevel gear pairs and slip clutch
Each corn head row is built with oil-bathed mechanical gear boxes with hardened steel bevel gear pairs.
Each row-group is also equipped with a slip clutch that protects its transmission components.
Reinforced steel gathering chains with hard chrome pins
The reinforced steel gathering chains with hard chrome pins are self-adjusted by a spin that absorbs all mechanical stress.
Knife stalk rollers
The interchangeable blades are made of tungsten carbide.
Weed knives
They prevent weed wrapping on the whole length.
Easy and quick maintenance
Thanks to a body equipped with special rapid quick-release mechanisms, transmission elements can be easily accessed (no tools needed for this operation) for a quicker maintenance.

Drago2: 4 to 24 rows, fixed or foldable
CUSTOMISED ACCORDING TO YOUR NEEDS

A complete product range
You can have your Drago2 from 4 to 24 rows, fixed or foldable, customized according to your needs.
Universal
Drago2 is universal and it can be applied on any type and brand of combine-harvester and self-propelled shredder.
Foldable from the operator’s platform
Drago2 is directly foldable from the operator’s driving seat. The reduced dimensions
(3-3,20 m) together with total visibility allow for convenient on-road transport.
Customisation
In Olimac there is a team of technicians who develops and fine-tunes special configurations to satisfy requests from each customer.
Support and original spare parts
A worldwide network of Olimac Authorized Centers, assures competent support and rapid response to solve any problem.

twenty-four-eighteen-eight-rows-Drago-2-corn-head
Three types of transmissions
IDEAL FOR ALL WORKING CONDITIONS
Olimac-Drago-2-tre-tipi-di-trasmissioni-super-performanti-zero-manutenzione-2-three-types-of-super-performing-transmissions-zero-maintenance-drei-sorten-superfunktionstuechtige-antriebe-null-wartung-tres-tipos-de-transmisiones-súper-performantes-cero-mantenimiento

A – Oil drop lubrication internal transmission

B – Oil-bathed external transmission with intermediate joint
High-performing transmission, zero maintenance, no re-lubrication required, total protection from impurities and foreign objects.
The intermediate joint allows the corn head to be folded for on-road transport without removing the cardan shaft.

C – Oil-bathed external transmission ideal for hill areas
High- performing transmission, zero maintenance, no re-lubrication required, total protection from impurities and foreign objects.
Ideal for hill areas.

Three-times long lasting painting
CORN HEAD LASTS MORE, EXCELLENT AESTHETICS
Olimac-verniciatura-dura-tre-volte-di-più-three-times-long-lasting-painting-dreimal-langer-haltbare-lackierung-barnizado-dura-tres-veces-más

Olimac plant, that is totally automatic and robotic, ensures a lifetime of the painting which is three times higher than the average of the sector: excellent aesthetics and longer life of the corn head are guaranteed.

Drago2 accessories
Drago-2-gomme-ferma-pannocchie-kit-schiacciastocchi-ear-stopping-rubber-elements-stalk-pressing-kit-gummihalterungen-fuer-maiskolben-bausatz-stoppel-quetscher-gomas-para-mazorcas-aplasta-mata

– Ear stopping rubber
Ideal on hill areas or different height

– Stalk pressing kit
Combine-harvester tyre protection

Drago-2-sensori-livellamento-barra-luci-levelling-sensors-bar-light-bar-sensoren-zur-automatische-hoehenjustierung-des-schneidevorsatzes-beleuchtungs-aufsatz-sensores-nivelación-barra-luces

– Sensors kit
Automatic leveling of the bar

– Light bar
For on-road transport

Drago-2-kit-girasole-griglia-anti-caduta-rotore-taglio-gambo-sunflower-kit-anti-fall-grid-sunflower-kit-stalk-cutting-rotor-bausatz-sonnenblumen-fallschutzgitter-bausatz-sonnenblumen-staengel-schnittrotor-rejilla-anti-caida-rotor-corte-tallo

– Sunflower kit
Fall protection grid and stalk cutting rotor

Drago-2-carter-cambio-direzionale-convogliatore-stocchi-slip-clutch-carter-stalk-conveyor-haecksler-leitbleche-staengel-foerderband-cambio-direccional-canalizador-mata

– Directional change crankcase

– Stalk conveyor on the chopping device

Olimac-Drago-2-in-all-corn-fields-of-the-world

Join the exclusive
Drago Club

Buying a Drago corn head you will make a step up in class which will allow you to carry on a more productive and profitable job, thanks to an innovative and worldwide unique technology.
